The SLG-E Cigarette Filter Length Tester is used to measure the length of cigarette and filter rod. The test bench adopts a drawer design, has high automation and is compatible with samples of various specifications, including regular cigarettes, medium cigarettes, thin cigarettes, special cigarettes, heat-not-burn cigarettes, common filter rods, medium filter rods, thin filter rods and special filter rods.
The test bench applies to multiple links in the cigarette and filter rod production, such as on-line sampling inspection in the production workshop, and inspection and spot check of cigarette and filter rod samples in testing stations and laboratories at all levels, etc. The test bench uses a Chinese( or another language of your option) operation interface, easy to operate and learn.
We supply physical characteristics testing instruments for tobacco industry. For example, the measuring and testing equipments for the bellow areas.
1. regular cigarette/filter rods
2. capsule cigarette/filter rods
3. heat-not-burn cigarettes
4. cigars
5. flavor capsules
We also can cater to your specific testing requirements and customized the tobacco insepction stations.
Performance and Features
1. It applies to cigarettes and filter rods with various specifications.
2. It adopts the industrial tablet computer, suitable for industrial field and other scenarios.
3. It adopts high-precision laser micrometer for non-contact measurement, with high precision and high resolution.
4. It adopts advanced technologies such as lightweight cylinder measurement holding system, rotary measurement benchmark automatic switching device.
5. It provides high-speed automatic measurement, Chinese graphical interface, and touch screen, easy to use and fast to master.
6. It provides a complete data processing function to exchange data through various interfaces for data sharing.
7. It provides Chinese( or another language of your option) graphical interface and touch screen, easy to use and quick to grasp; It adopts a built-in thermal printer for real-time printing of measurement results.
8. It is configured with USB, RS232 and network interfaces to support data acquisition.
Technical parameters
| Sample length range |
55 ~ 150mm |
| Sample circumference range |
15.5 ~ 28.5mm |
| Measurement range |
55~150mm |
| Resolution |
±0.005mm |
| Precision |
±0.01mm |
| Overall size |
Host 570x600x620mm (without computer), stand 560x520x740mm |
