RCT-I Capsule Cigarette Filter Rod Tester adopts the microwave resonant cavity measurement technology and high-precision servo drive device to detect the position, quantity, damage and loss of the capsules in the capsule filter rod, and can screen unqualified products according to the preset parameters. It has the advantages of real-time detection, high precision and no damage to filter rod. It meets the detection requirements in the production, inspection, experimental research of various specifications of capsule cigarettes/filter rods. It is used for detecting the position, quantity, damage and loss of the capsules in the capsule cigarette/filter rod, and screening unqualified products in real time.
When a filter rod with a certain dielectric constant enters the microwave resonant cavity, the perturbation phenomenon is generated in the cavity; by measuring the variation of frequency f and quality factor Q after the perturbation, the electromagnetic characteristics of each part of the detected filter rod can be calculated by using a linear regression method, and whether the capsule filter rod/cigarette is qualified is judged on this basis.
We supply physical characteristics testing instruments for tobacco industry. For example, the measuring and testing equipments for the bellow areas.
1. regular cigarette/filter rods
2. capsule cigarette/filter rods
3. heat-not-burn cigarettes
4. cigars
5. flavor capsules
We also can cater to your specific testing requirements and customized the tobacco insepction stations.
Performance and Features
1 . It can detect the capsule filter rods and capsule cigarettes.
2. It adopts the microwave resonant cavity measurement technology to detect the capsule in the filter rod, with the sampling rate of 100k/s.
3. It can detect the position, quantity, damage and loss of the capsule in the filter rod quickly and without damage.
4. It adopts the Beckhoff IPC control technology and EtherCAT high-speed data transmission technology.
5. It adopts the servo electric cylinder to convey the capsule filter rod, thus ensuring the accuracy of position detection.
6. The hopper is fully compatible and can be automatically switched to adapt to different specifications of samples.
7. The hopper has a movable flap to prevent sample mix-up and can accommodate a variety of sample lengths.
8. The whole machine adopts desktop design, with small volume and light weight.
9. It adopts 15-inch touch display, windows system, and Chinese graphical interface, easy to use.
Technical parameters
| Detection mode |
Continuous detection, automatic sieving |
| Diameter range of capsule filter rod |
5.0 ~ 8.0mm |
| Length range of capsule filter rod |
60 ~ 150mm |
| Minimum distance between capsules |
≥6mm |
| Minimum distance from capsule to end face |
≥6mm |
| Capsule diameter |
≥2.4mm |
| Measurement accuracy |
±0.15mm |
| Measurement speed |
30 pcs/min |
| Hopper capacity |
≥150 pcs |
| Capsule color |
Unlimited |
| Overall size |
870 x 440x680mm |
