The SDRG-E Cigarette Filter Draw Resistance Tester is used to measure the cigarette draw resistance and the filter rod pressure drop. The test bench adopts a drawer design, has high automation and is compatible with samples of various specifications, including regular cigarettes, medium cigarettes, thin cigarettes, special cigarettes, heat-not-burn cigarettes, common filter rods, medium filter rods, thin filter rods and special filter rods.
The test bench applies to multiple links in the cigarette and filter rod production, such as on-line sampling inspection in the production workshop, and inspection and spot check of cigarette and filter rod samples in testing stations and laboratories at all levels, etc. The test bench uses a Chinese( or another language of your option) operation interface, easy to operate and learn.
Performance and Features
1. It applies to cigarettes and filter rods with various specifications.
2. It adopts the industrial tablet computer, suitable for industrial field and other scenarios.
3. It adopts the imported high-precision pressure sensor, the pressure transmitter, and the CFO constant current element made of precious stones.
4. It adopts advanced technology such as inclined plane jointing and positioning device to ensure reliable sealing.
5. It provides automatic measurement with high precision, and imported valve terminal electrical control circuit with high reliability, easy to use and maintain.
6. It provides Chinese graphical interface and touch screen, easy to use and quick to grasp; It adopts a built-in thermal printer for real-time printing of measurement results.
7. It is configured with USB, RS232 and network interfaces to support data acquisition.
Technical parameters
| Sample length range |
55 ~ 150mm |
| Sample circumference range |
15.5 ~ 28.5mm |
| Measurement range |
Draw resistance: 0~10,000 Pa (customizable, up to 0~15,000Pa)
Ventilation rate: 0~100%
|
| Resolution |
Draw resistance: 1 pa |
Ventilation rate: 0.1% |
| Precision |
Draw resistance: ±0.5%FS |
Ventilation rate: ±1.0%FS |
| Constant air velocity |
17.5±0.1ml/s |
| Overall size |
Host 570x600x620mm (without computer), stand 560x520x740mm |
We supply physical characteristics testing instruments for tobacco industry. For example, the measuring and testing equipments for the bellow areas.
1. regular cigarette/filter rods
2. capsule cigarette/filter rods
3. heat-not-burn cigarettes
4. cigars
5. flavor capsules
We also can cater to your specific testing requirements and customized the tobacco insepction stations.
